Ibanez GA6CE-AM Classical Guitar
-
SPECS
-
body shapeCutaway Classical body
-
bracingFan bracing
-
topSpruce top
-
back & sidesSapele back & Sapele sides
-
neckOkoume
-
fretboardPurpleheart fretboard
-
bridgePurpleheart
-
body bindingBlack
-
soundhole rosetteClassical Mosaic Design rosette
-
tuning machineGold Classical tuners
-
number of frets19
-
stringsCoated nylon strings
-
string space11.6mm
-
pickupIbanez Undersaddle pickup
-
preampIbanez AEQ-2T preamp w/Onboard tuner
-
output jack1/4" output
-
battery9V battery
-
finish topGloss
-
finish back and sidesGloss
-
finish neck backGloss
-
-
NECK DIMENSIONS
-
-
Scale :650mm/25.6"
-
a : Width52mm at NUT
-
b : Width63.5mm at 14F
-
c : Thickness22mm at 1F
-
d : Thickness24mm at 7F
-
Radius :Flat
-
-
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
-
-
BODY DIMENSIONS
-
-
a : Length19 1/4"
-
b : Width14 1/2"
-
c : Max Depth4 "
-
-
DESCRIPTION
Guitar Body Diagram
A: Length of the body
B: Maximum width of the body
C: Maximum depth of the body
-
-
PREAMP
DESCRIPTION
The neck side of the preamp is the top of the control panel. There is one button and three knobs along the top of the control panel. The button furthest to the left is the tuner on/off switch. To the right of that are the bass, treble, and volume knobs.
